LINESCAPES SYSTEM

Linescapes est un système modulaire de lignes et d’angles continus, reliés par des joints en polymère moulé qui permettent une connexion rapide et une rotation à 360°. Le système Linescapes a été conçu dans le but d’offrir une polyvalence de conception extrême grâce à une installation simplifiée et un entretien facile.

Technical drawing

SEGMENTSPOTCONNECTIONLEDACCESSORIES4010636/56/106/17136/56/106/17136/56/106/171WINGLINK567,5Ø3,540106567,5Ø3,564T UP VERTICAL44UP VERTICAL ANGLECENTRAL1212HORIZONTALEND14WALL CEILINGEND + XYZ12HORIZONTALSTART64T DOWN VERTICAL44DOWN VERTICAL ANGLE12CENTRAL ONE WAY12VERTICALENDVERTICALANGLE SUPPLY12VERTICALSTART6464T HORIZONTAL44HORIZONTAL ANGLE12CENTRAL SUPPLY10WALL CEILINGENDHORIZONTALANGLE SUPPLY10WALL CEILINGSTART44POWER SUPPLY2955255,57CEILING PLATE1010CANOPY3Ø11SPOT TIGE7,5Ø3,57,5Ø3,5

Versions

  • LED SEGMENTS
    • 36cm - 2700K
      Linear LED6W335lm diffused orientable 360°2700Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW8 51 whiteCode/ColorLSS LN8 51 black
    • 56cm - 2700K
      Linear LED9,5W600 lm diffused orientable 360°2700K dimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW7 51 whiteCode/ColorLSS LN7 51 black
    • 106cm - 2700K
      linear LED19W1125lm diffused orientable 360°2700Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW6 51 whiteCode/ColorLSS LN6 51 black
    • 171cm - 2700K
      linear LED33W1765lm diffused orientable 360°2700Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW5 51 whiteCode/ColorLSS LN5 51 black
    • 36cm - 3000K
      linear LED6W335lm diffused, orientable 360°3000Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW4 51 whiteCode/ColorLSS LN4 51 black
    • 56cm - 3000K
      linear LED9,5W600lm diffused, orientable 360°3000Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW3 51 whiteCode/ColorLSS LN3 51 black
    • 106cm - 3000K
      linear LED19W1125lm diffused, orientable 360°3000Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW2 51 whiteCode/ColorLSS LN2 51 black
    • 171cm - 3000K
      linear LED33W1765lm diffused, orientable 360°3000Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS LW1 51 whiteCode/ColorLSS LN1 51 black
  • LINK SEGMENTS
    • 36cm
      24V electrical connection, orientable 360°, no light
      aluminium + PC + ABSCode/ColorLSS BW4 51 whiteCode/ColorLSS BN4 51 black
    • 56cm
      24V electrical connection, orientable 360°, no light
      aluminium + PC + ABSCode/ColorLSS BW3 51 whiteCode/ColorLSS BN3 51 black
    • 106cm
      24V electrical connection, orientable 360°, no light
      aluminium + PC + ABSCode/ColorLSS BW2 51 whiteCode/ColorLSS BN2 51 black
    • 171cm
      24V electrical connection, orientable 360°, no light
      aluminium + PC + ABSCode/ColorLSS BW1 51 whiteCode/ColorLSS BN1 51 black
  • WING SEGMENTS
    • 36cm - 2700K
      Linear LED6W335lm diffused orientable 360°2700Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW8 51 whiteCode/ColorLSS UN8 51 black
    • 56cm - 2700K
      Linear LED9,5W 600lm diffused orientable 360°2700Kdimmable according to driver24V DC
      85A+20orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW7 51 whiteCode/ColorLSS UN7 51 black
    • 106cm - 2700K
      Linear LED19W1125lm diffused orientable 360°2700Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW6 51 whiteCode/ColorLSS UN6 51 black
    • 171cm - 2700K
      Linear LED33W1765lm diffused orientable 360°2700Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW5 51 whiteCode/Color LSS UN5 51 black
    • 36cm - 3000K
      Linear LED6W 335lm diffused orientable 360° 3000Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW4 51 whiteCode/ColorLSS UN4 51 black
    • 56cm - 3000K
      Linear LED9,5W600lm diffused orientable 360°3000K dimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW3 51 whiteCode/ColorLSS UN3 51 black
    • 106cm - 3000K
      Linear LED19W1125lm diffused orientable 360° 3000Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW2 51 whiteCode/ColorLSS UN2 51 black
    • 171cm - 3000K
      Linear LED 33W1765lm diffused, orientable 360° 3000Kdimmable according to driver24V DC
      8020orientable 360°
      aluminium + PC + ABSCode/ColorLSS UW1 51 whiteCode/ColorLSS UN1 51 black
  • SPOT SEGMENTS
    • TIGE 2 SPOT 56cm - 2700K
      LED board2x4W2x400lm spot light, orientable 360° 2700Kdimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW1 51 whiteCode/ColorLSS SN1 51 black
    • TIGE 3 SPOT 106cm - 2700K
      LED board3x4W3x400lm spot light, orientable 360° 2700Kdimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW2 51 whiteCode/ColorLSS SN2 51 black
    • TIGE 2 SPOT 56cm - 3000K
      LED board2x4W2x400lm spot light, orientable 360° 3000K dimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW3 51 whiteCode/ColorLSS SN3 51 black
    • TIGE 3 SPOT 106cm - 3000K
      LED board3x4W 3x400lm spot light, orientable 360° 3000K dimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW4 51 whiteCode/ColorLSS SN4 51 black
    • 2 SPOT 56cm - 2700K
      LED noard2x4W2x400lm spot light, orientable 360° 2700Kdimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW5 51 whiteCode/ColorLSS SN5 51 black
    • 2 SPOT 56cm - 3000K
      LED board2x4W2x400lm spot light, orientable 360° 3000Kdimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW7 51 whiteCode/ColorLSS SN7 51 black
    • 4 SPOT 106cm - 2700K
      LED SPOT 2x4W4x400lm spot light, orientable 360° 2700Kdimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW6 51 whiteCode/ColorLSS SN6 51 black
    • 4 SPOT 106cm - 3000K
      LED board2x4W4x400lm diffused, orientable 360° 3000Kdimmable according to driver24V DC
      9020orientable 90°/340°
      metal + PMMA + PC + ABSCode/ColorLSS SW8 51 whiteCode/ColorLSS SN8 51 black
  • CONNECTIONS
    • T UP VERTICAL
      20cable length 3m
      PC+ABSCode/ColorLSS TN2 51 blackCode/ColorLSS TW2 51 white
    • T DOWN VERTICAL
      20
      PC+ABSCode/ColorLSS TN1 51 blackCode/ColorLSS TW1 51 white
    • T HORIZONTAL
      20cable length 3m
      PC+ABSCode/ColorLSS TN3 51 blackCode/ColorLSS TW3 51 white
    • UP VERTICAL ANGLE
      20cable length 3m
      PC+ABSCode/ColorLSS AW1 51 whiteCode/ColorLSS AN1 51 black
    • DOWN VERTICAL ANGLE
      20
      PC+ABSCode/ColorLSS AW2 51 whiteCode/ColorLSS AN2 51 black
    • HORIZONTAL ANGLE
      20cable length 3m
      PC+ABSCode/ColorLSS AW3 51 whiteCode/ColorLSS AN3 51 black
    • CENTRAL
      20cable length 3m
      PC+ABSCode/ColorLSS CW5 51 whiteCode/ColorLSS CN5 51 black
    • CENTRAL ONE WAY
      20cable length 3m
      PC+ABSCode/ColorLSS CW7 51 whiteCode/ColorLSS CN7 51 black
    • CENTRAL SUPPLY
      20cable length 3m
      PC+ABSCode/ColorLSS CW4 51 whiteCode/ColorLSS CN4 51 black
    • HORIZONTAL START
      20cable length 3m
      PC+ABSCode/ColorLSS CW2 51 whiteCode/ColorLSS CN2 51 black
    • VERTICAL START
      20cable length 3m
      PC+ABSCode/ColorLSS CW1 51 whiteCode/ColorLSS CN1 51 black
    • WALL CEILING START
      20
      PC+ABSCode/ColorLSS FW3 41 whiteCode/ColorLSS FN3 41 black
    • HORIZONTAL END
      20cable length 3m
      PC+ABSCode/ColorLSS CW3 51 whiteCode/ColorLSS CN3 51 black
    • VERTICAL END
      20cable length 3m
      PC+ABSCode/ColorLSS CW6 51 whiteCode/ColorLSS CN6 51 black
    • WALL CEILING END
      20
      PC+ABSCode/ColorLSS FW1 41 whiteCode/ColorLSS FN1 41 black
    • WALL CEILING + XYZ
      20
      PC+ABSCode/ColorLSS FW2 4 whiteCode/ColorLSS FN2 41 black
    • VERTICAL ANGLE SUPPLY
      20cable length 3m
      PC+ABSCode/ColorLSS AW4 51 whiteCode/ColorLSS AN4 51 black
    • HORIZONTAL ANGLE SUPPLY
      20cable length 3m
      PC+ABSCode/ColorLSS AW5 51 whiteCode/ColorLSS AN5 51 black
  • DESK MATRIX
    • 44x44cm - HORIZONTAL 2700K
      Linear LED 24W1340lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 51 whiteCode/ColorLSH LN2 51 black
    • 44x44cm - VERTICAL 2700K
      Linear LED 24W1340lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 51 whiteCode/ColorLSV LN2 51 black
    • 44x44cm - HORIZONTAL 3000K
      Linear LED 24W1340lm diffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 51 whiteCode/ColorLSH LN3 51 black
    • 44x44cm - VERTICAL 3000K
      Linear LED 24W1340lm diffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 51 whiteCode/ColorLSV LN3 51 black
    • 64x44cm - HORIZONTAL 2700K
      Linear LED 31W1870lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 55 whiteCode/ColorLSH LN2 55 black
    • 64x44cm - VERTICAL 2700K
      Linear LED 31W1870lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 55 whiteCode/ColorLSV LN2 55 black
    • 64x44cm - HORIZONTAL 3000K
      Linear LED 31W1870lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 55 whiteCode/ColorLSH LN3 55 black
    • 64x44cm - VERTICAL 3000K
      Linear LED 31W1870lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 55 whiteCode/ColorLSV LN3 55 black
    • 114x44cm - HORIZONTAL 2700K
      Linear LED 50W2920lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 58 whiteCode/ColorLSH LN2 58 black
    • 114x44cm - VERTICAL 2700K
      Linear LED 50W2920lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 58 whiteCode/ColorLSV LN2 58 black
    • 114x44cm - HORIZONTAL 3000K
      Linear LED 50W2920lm diffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 58 whiteCode/ColorLSH LN3 58 black
    • 114x44cm - VERTICAL 3000K
      Linear LED 50W2920lm diffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 58 whiteCode/ColorLSV LN3 58 black
    • 178x44cm - HORIZONTAL 2700K
      Linear LED 78W4200lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 5A whiteCode/ColorLSH LN2 5A black
    • 178x44cm - VERTICAL 2700K
      Linear LED 78W4200lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 5A whiteCode/ColorLSV LN2 5A black
    • 178x44cm - HORIZONTAL 3000K
      Linear LED 78W4200lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 5A whiteCode/ColorLSH LN3 5A black
    • 178x44cm - VERTICAL 3000K
      Linear LED 78W4200lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 5A whiteCode/ColorLSV LN3 5A black
    • 64x64cm - HORIZONTAL 2700K
      Linear LED 38W2400lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 52 whiteCode/ColorLSH LN2 52 black
    • 64x64cm - VERTICAL 2700K
      Linear LED 38W2400lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 52 whiteCode/ColorLSV LN2 52 black
    • 64x64cm - HORIZONTAL 3000K
      Linear LED 38W2400lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 52 whiteCode/ColorLSH LN3 52 black
    • 64x64cm - VERTICAL 3000K
      Linear LED 38W2400lm diffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 52 whiteCode/ColorLSV LN3 52 black
    • 114x64cm - HORIZONTAL 2700K
      Linear LED 57W3450lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 56 whiteCode/ColorLSH LN2 56 black
    • 114x64cm - VERTICAL 2700K
      Linear LED 57W3450lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 56 whiteCode/ColorLSV LN2 56 black
    • 114x64cm - HORIZONTAL 3000K
      Linear LED 57W3450lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 56 whiteCode/ColorLSH LN3 56 black
    • 114x64cm - VERTICAL 3000K
      Linear LED 57W3450lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 56 whiteCode/ColorLSV LN3 56 black
    • 178x64cm - HORIZONTAL 2700K
      Linear LED 85W4730lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 59 whiteCode/ColorLSH LN2 59 black
    • 178x64cm - VERTICAL 2700K
      Linear LED 85W4730lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 59 whiteCode/ColorLSV LN2 59 black
    • 178x64cm - HORIZONTAL 3000K
      Linear LED 85W4730lm diffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 59 whiteCode/ColorLSH LN3 59 black
    • 178x64cm - VERTICAL 3000K
      Linear LED 85W4730lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 59 whiteCode/ColorLSV LN3 59 black
    • 114x114cm - HORIZONTAL 2700K
      Linear LED 76W4500lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 53 whiteCode/ColorLSH LN2 53 black
    • 114x114cm - VERTICAL 2700K
      Linear LED 76W4500lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 53 whiteCode/ColorLSV LN2 53 black
    • 114x114cm - HORIZONTAL 3000K
      Linear LED 76W4500lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 53 whiteCode/ColorLSH LN3 53 black
    • 114x114cm - VERTICAL 3000K
      Linear LED 76W4500lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 53 whiteCode/ColorLSV LN3 53 black
    • 178x114cm - HORIZONTAL 2700K
      Linear LED 104W5780lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 57 whiteCode/ColorLSH LN2 57 black
    • 178x114cm - VERTICAL 2700K
      Linear LED 104W5780lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 57 whiteCode/ColorLSV LN2 57 black
    • 178x114cm - HORIZONTAL 3000K
      Linear LED 104W5780lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 57 whiteCode/ColorLSH LN3 57 black
    • 178x114cm - VERTICAL 3000K
      Linear LED 104W5780lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 57 whiteCode/ColorLSV LN3 57 black
    • 178x178cm - HORIZONTAL 2700K
      Linear LED 132W7060lm diffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW2 54 whiteCode/ColorLSH LN2 54 black
    • 178x178cm - VERTICAL 2700K
      Linear LED 132W7060lmdiffused, orientable 360° on all four sides2700Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW2 54 whiteCode/ColorLSV LN2 54 black
    • 178x178cm - HORIZONTAL 3000K
      Linear LED 132W7060lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSH LW3 54 whiteCode/ColorLSH LN3 54 black
    • 178x178cm - VERTICAL 3000K
      Linear LED 132W7060lmdiffused, orientable 360° on all four sides3000Kdimmable 1-10V110/240V
      8520driver included, adjustable cable length max 3m
      aluminium + PC + ABSCode/ColorLSV LW3 54 whiteCode/ColorLSV LN3 54 black
  • CEILING PLATE
    10x10cm
    aluminumCode/ColorLSS PWR 51 whiteCode/ColorLSS PNR 51 black
  • CANOPY
    Ø11x3cm
    metalCode/ColorROS KWW 51 whiteCode/ColorROS KNN 51 black
  • POWER SUPPLY
    • 60W 1-10V
      1-10V110/240V
      25x7x5,5cm
      Code/ColorLSS PW6 51 whiteCode/ColorLSS PN6 51 black
    • 90W 1-10V
      1-10V110/240V
      29x5x5cm
      Code/ColorLSS PW9 51 whiteCode/ColorLSS PN9 51 black
  • REMOTE DRIVERS
    • 1-10V 25W
      110/240V
      14,8x4x3,2cm
      Code/ColorLIN ALI 32
    • 1-10V 60W
      110/240V
      16,8x4,3x3,2cm
      Code/ColorLIN ALI 31
    • 1-10V 90W
      110/240V
      16x6x3,6cm
      Code/ColorLIN ALI 34
    • 1-10V 150W
      110/240V
      22,8x6,8x4cm
      Code/ColorLIN ALI 35
    • 1-10V 185W
      110/240V
      22,8x6,8x4cm
      Code/ColorLIN ALI 36
    • 1-10V 240W
      110/240V
      24,5x6,8x4cm
      Code/ColorLIN ALI 37
    • 1-10V 320W
      110/240V
      25,2x9x4,4cm
      Code/ColorLIN ALI 38
    • DALI 100W
      110/240V
      20x6,3x3,6cm
      Code/ColorLIN ALI 51
    • DALI 150W
      110/240V
      22x6,3x3,6cm
      Code/ColorLIN ALI 52
    • DALI 200W
      110/240V
      24,4x7x3,8cm
      Code/ColorLIN ALI 53
    • DALI 240W
      110/240V
      24,4x7x3,6cm
      Code/ColorLIN ALI 54
    • Empty box
      31x8x6cm
      Code/ColorROS LNN 51 blackCode/ColorROS LWW 51 white

Download

Family

DESK MATRIXDécouvrir
Projects

Villa Corse

Projects

Work Agency Headquarter, Milan

Projects

Penthouse in Milan

Projects

Perah Hashaked Offices, Tel Aviv

Stay connected

Inscrivez-vous à la newsletter pour rester informé des dernières nouvelles

For a better experience please rotate your smartphone in portrait mode

Download

Remplissez le formulaire suivant pour télécharger le fichier souhaité

NEMO Group

If you have any question, please contact us

Write us to be contacted by one of our consultants and arrange a tailor-made shipment for you.

You are about to be directed to the new Ilti Luce website:

iltiluce.com
